Corian PVC/PP/PE/Acrylic/Plastic Vacuum Thermoforming Machine/Film Vacuum Forming Machine

The thermoforming membrane vacuum presses BSF1325 is designed special for solid surface materials(Corian, Hi Macs, Staron, Hanex, Kerrock and others) preheating and shaping, as well an acrylic ma

Featured Products

PVC/PP/PE /Acrylic/Plastic Vacuum Thermo Former/Membrane Vacuum Forming Machine for Corian


The thermoforming membrane vacuum presses BSF1325 is designed special for solid surface materials(Corian, Hi Macs, Staron, Hanex, Kerrock and others) preheating and shaping, as well an acrylic material and a
thermoplastic forming. Capacities and sized could also be costomized, this machine combined solution which including functions of two separate machines a vacuum press and the preheating oven, greatly increases its functionality.


Features
1. Temperature control with PID regulation, two-side preheating oven.

2.Heating plate from anodized aluminum.

3.Pneumatic actuator for upper heating plate, high performance.

4.Stainless steel heaters, life of up to 15000 hours.

5.Imported silicone membrane with 700% elasticity, working temperature between -40ºC to 240ºC, long life service.

6.Oil free vacuum pump with capacity 60m³/h.

7.Work table from fire-resisted laminate plate with grooves, ensure the good performance.

Area of application

corian vacuum former/vacuum thermoforming machines
Work table from 12mm HPL board;
Imported Silicone membrane from Korea 3mm thick, 700% elasticity;
Oil free vacuum pump with capacity 60m3/h;
System of vacuum control and automatic pump stop;
Two-side preheating oven;
Temperature control with PID regulation;
Heating plate from anodized aluminium;
Pneumatic actuator of upper plate of heating.


Corian vacuum forming machine working video as below :

http://youtu.be/kZI7TJ62FYg


Beside the vacuum forming machine , we also produce other machine such as :
1.CNC router
2.CNC plasma cutting machine
3.Channel letter bending machine
4.Laser cutting and engraving machine


 Technical data BFS-2513
 Working table size  1200*2400mm
 Heating area  2000*1000mm
 Forming area  2240*1020mm
 Material Thickness  0-20mm
 power  23kw
 vacuum pump power  2.2kw
 Max forming height  500mm
 voltage  380v 50hz 3p
